A comprehensive solution for installation, refurbishment and maintenance
3 x 360°-Laser lines - form 6 laser crosses
Laser lines switchable separately
Plumbing function
Minimum laser line distance to floor 8 mm
Minimum laser line distance to wall 6 mm
Height adjustable platform from 25 to 85 mm
Wall-mount
Height and side adjustable
Can be fixed to a wall
Attachment to magnetic surfaces
Strap attachment
Visual and audible alarm when out of level
Self-levelling function can be locked for manual use
5/8“ thread for use with tripods etc. (bottom / face adaptor)
1/4“ thread for use with adaptor etc. (top side)
Use with receiver FR 75-MM / FR 55 / FR 55-M (optional)
Li-Ion battery
Battery case for alkaline batteries
Height adjustable platform
Wall-mount
Support rail
20 mm Fixed height adaptor with 5/8“
3x Height measurement pins
Magnetic target
Container
Self-levelling range ± 3°
Accuracy ± 2 mm / 10 m
Laser diode / class green / 2
Working range without receiver 40 m* (radius)
Working range with receiver 60 m** (radius)
Operating time / Power supply
1 x 360° 15 h / Li-Ion
2 x 360° 7 h / Li-Ion
3 x 360° 5 h / Li-Ion
Dust/water-protection IP 54
Temperature range -10°C to +45°C
Size 115 x 96 x 118 mm
Weight (instrument with battery) 0,8 kg
* depending on room illumination
** depending on direction of laser
